Bench drill press

REF : 111212
DPC 35E
GENCOD / EAN : 3431541112124
Brand : Fartools PRO

     Technical informations
     Consummables
     Accessories
     Complementary products
     Similar products
     Spare parts
     Downloads

    Technical informations

    tension 230 V
    type Etabli
    Power 750 W
    type of setting Cône morse CM3/MT3
    distance between spindle and c 176 MM
    type of construction Fonte
    rotary speed 150-3000 TR/MIN
    chuck tightening system auto serrant
    chuck tightening capacity 1-16 MM
    digital display
    emergency stop
    size of the main table 290 MM
    height 1060 MM
    arbor lock
    lighting
    laser target
    type of electronic variable sp Mécanique
    thermic security MAN
    thermic security AUTO
    incline of the table
    spindle travel 80 MM
    laser supply 2x1,5V VOLTS
    packaging Carton
    automatic lubrificate
    adjustable support
    column diameter 80 MM
    number of mecanic speed x16
    setting by the rack
